# Tidy your time series analysis with tsibble
### Earo Wang @earowang
### 4 October 2018 slides at <a href="http://slides.earo.me/bigapple" class="uri">http://slides.earo.me/bigapple</a>

---

# 2017 US airline traffic: 5,548,445 flights

*data source: [US Bureau of Transportation Statistics](https://www.transtats.bts.gov/DL_SelectFields.asp?Table_ID=236)*

???

we're looking at time series analysis from EDA perspective, what data we're going to look at?

---

```r
glimpse(flights)
```

```
#> Observations: 5,548,445
#> Variables: 22
#> $ flight <chr> "AA494", "AA494", "AA494", ...
#> $ sched_dep_datetime <dttm> 2017-01-17 16:19:00, 2017-...
#> $ sched_arr_datetime <dttm> 2017-01-17 18:56:00, 2017-...
#> $ dep_delay <dbl> -3, -5, -8, 37, 13, 17, -3,...
#> $ arr_delay <dbl> -14, -35, -30, 33, 2, 25, 1...
#> $ carrier <chr> "AA", "AA", "AA", "AA", "AA...
#> $ tailnum <chr> "N583AA", "N544AA", "N553AA...
#> $ origin <chr> "CLT", "CLT", "CLT", "CLT",...
#> $ dest <chr> "PHX", "PHX", "PHX", "PHX",...
#> $ air_time <dbl> 244, 228, 236, 252, 245, 25...
#> $ distance <dbl> 1773, 1773, 1773, 1773, 177...
#> $ origin_city_name <chr> "Charlotte", "Charlotte", "...
#> $ origin_state <chr> "NC", "NC", "NC", "NC", "NC...
#> $ dest_city_name <chr> "Phoenix", "Phoenix", "Phoe...
#> $ dest_state <chr> "AZ", "AZ", "AZ", "AZ", "AZ...
#> $ taxi_out <dbl> 17, 13, 17, 18, 17, 27, 20,...
#> $ taxi_in <dbl> 5, 6, 2, 3, 4, 4, 7, 6, 5, ...
#> $ carrier_delay <dbl> NA, NA, NA, 33, NA, 0, NA, ...
#> $ weather_delay <dbl> NA, NA, NA, 0, NA, 0, NA, N...
#> $ nas_delay <dbl> NA, NA, NA, 0, NA, 8, NA, N...
#> $ security_delay <dbl> NA, NA, NA, 0, NA, 0, NA, N...
#> $ late_aircraft_delay <dbl> NA, NA, NA, 0, NA, 17, NA, ...
```
]

???

detailed, and richness

---

### .bg-col[.white[When a plane goes somewhere, it comes back.]]

# Plane N938DN

???

tailnum

---

### .bg-col[.white[The flight number isn't tied to a certain path.]]

# Flight DL771

???

* flight number is such a weir variable.

---

```
#> # A tibble: 5,548,445 x 3
#> flight origin sched_dep_datetime
#> <chr> <chr> <dttm>
#> 1 AA494 CLT 2017-01-17 16:19:00
#> 2 AA494 CLT 2017-01-18 16:19:00
#> 3 AA494 CLT 2017-01-19 16:19:00
#> 4 AA494 CLT 2017-01-20 16:19:00
#> 5 AA494 CLT 2017-01-21 16:19:00
#> 6 AA494 CLT 2017-01-22 16:19:00
#> # ... with 5.548e+06 more rows
```
]

???

* event data --> slide into time series analysis

---

.pull-right[





This data set features:
* heterogeneous data types
* irregular time interval
* multiple measured variables
* multiple grouping variables
]

---

The underlying structure is a numeric matrix with implicit time indices.
]

---

The underlying structure is a numeric matrix with implicit time indices.
]
]

---

---

.pull-left[
<img src="https://imgs.xkcd.com/comics/standards.png">
.footnote[
.red[reference:] [XKCD on "standards"](https://xkcd.com/927/)
]
]

???

not sure if tsibble actually covers everyone's use case, but it is more accessible.

---

.left-column[






## What makes a tsibble?
]
.right-column[
.pull-left[

.center[
<img src="img/tibble.png" height=180px>

<img src="img/tsibble.png" height=180px>
]
]
.pull-right[






tsibble leverages tibble along with time domain semantics: **index** and **key**.
]
]

---

```r
us_flights <- flights %>%
 as_tsibble(
 index = sched_dep_datetime, key = id(flight, origin),
 regular = FALSE
 )
```
* Supported index types:
 + **base**: `POSIXct` & `Date`
 + **tsibble**: `yearweek`, `yearmonth` & `yearquarter`
 + **zoo**: `yearmth` & `yearqtr`
 + **nanotime**: `nanotime`
 + `integer`/`double`
* Extensible: define `index_valid()` for custom types
]

---

.left-column[
## What makes a tsibble?
### - index
### - key
]
.right-column[
What's your observational unit over time?

```r
us_flights <- flights %>%
 as_tsibble(
 index = sched_dep_datetime, key = id(flight, origin),
 regular = FALSE
 )
```

<img src="figure/dl771b-1.svg" style="display: block; margin: auto;" />
]

---

.left-column[
## What makes a tsibble?
### - index
### - key
]
.right-column[
What's your observational unit over time?

```r
us_flights <- flights %>%
 as_tsibble(
 index = sched_dep_datetime, key = id(flight, origin),
 regular = FALSE
 )
```
* Key created via `id()` (identifier)
 + *empty:* univariate time series (implicit key) `id()`
 + *single:* univariate or multivariate time series `id(flight)`
 + *multiple:* relational structures (nesting or crossing) `id(flight, origin | origin_city_name | origin_state)`

**tsibble is strict: distinct rows identified by index and key.** Use `validate = FALSE` to skip the checks, if you're sure it's a valid input.
]

---

.left-column[
## What makes a tsibble?
### - index
### - key
### - interval
]
.right-column[
Free from specifying time frequency

```r
us_flights <- flights %>%
 as_tsibble(
 index = sched_dep_datetime, key = id(flight, origin),
 regular = FALSE
 )
```

By default `regular = TRUE`, it automatically recognizes the time interval based on the index representation from year to day, to nanosecond.

But if you wanna specify the interval, check out the low-level constructor `build_tsibble()`.
]

---

.left-column[
## What makes a tsibble?
### - index
### - key
### - interval
### - tsibble
]
.right-column[
**Arranging the key and index from past to future**

```r
us_flights
```

```
#> # A tsibble: 5,548,445 x 22 [!]
#> # Key: flight, origin [161,976]
#> flight sched_dep_datetime sched_arr_datetime dep_delay
#> <chr> <dttm> <dttm> <dbl>
#> 1 AA1 2017-01-01 08:00:00 2017-01-01 11:42:00 31
#> 2 AA1 2017-01-02 08:00:00 2017-01-02 11:42:00 -3
#> 3 AA1 2017-01-03 08:00:00 2017-01-03 11:42:00 -6
#> 4 AA1 2017-01-04 08:00:00 2017-01-04 11:42:00 -3
#> 5 AA1 2017-01-05 08:00:00 2017-01-05 11:42:00 -7
#> 6 AA1 2017-01-06 08:00:00 2017-01-06 11:42:00 -3
#> # ... with 5.548e+06 more rows, and 18 more variables:
#> # arr_delay <dbl>, carrier <chr>, tailnum <chr>,
#> # origin <chr>, dest <chr>, air_time <dbl>,
#> # distance <dbl>, origin_city_name <chr>,
#> # origin_state <chr>, dest_city_name <chr>,
#> # dest_state <chr>, taxi_out <dbl>, taxi_in <dbl>,
#> # carrier_delay <dbl>, weather_delay <dbl>,
#> # nas_delay <dbl>, security_delay <dbl>,
#> # late_aircraft_delay <dbl>
```
]

---

.large[A tsibble consists of a *time index*, *key* and other *measured variables* in a **data-centric** format, which is built on top of the tibble.]

* arbitrary index support
* nesting and crossing data structures
* heterogeneous data types
* list-column

???

We learned a new time series standard, but what can we do with it?

---

## standing on the shoulders of giants

.animated.bounceInRight[

```
⬢ __ _ __ . ⬡ ⬢ .
 / /_(_)__/ /_ ___ _____ _______ ___
/ __/ / _ / // / |/ / -_) __(_-</ -_)
\__/_/\_,_/\_, /|___/\__/_/ /___/\__/
 ⬢ . /___/ ⬡ . ⬢
```
]

---

```r
us_flights %>%
 filter(sched_dep_datetime < yearmonth("201703"))
```

```
#> # A tsibble: 821,912 x 22 [!]
#> # Key: flight, origin [46,960]
#> flight sched_dep_datetime sched_arr_datetime dep_delay
#> <chr> <dttm> <dttm> <dbl>
#> 1 AA1 2017-01-01 08:00:00 2017-01-01 11:42:00 31
#> 2 AA1 2017-01-02 08:00:00 2017-01-02 11:42:00 -3
#> 3 AA1 2017-01-03 08:00:00 2017-01-03 11:42:00 -6
#> 4 AA1 2017-01-04 08:00:00 2017-01-04 11:42:00 -3
#> 5 AA1 2017-01-05 08:00:00 2017-01-05 11:42:00 -7
#> 6 AA1 2017-01-06 08:00:00 2017-01-06 11:42:00 -3
#> # ... with 8.219e+05 more rows, and 18 more variables:
#> # arr_delay <dbl>, carrier <chr>, tailnum <chr>,
#> # origin <chr>, dest <chr>, air_time <dbl>,
#> # distance <dbl>, origin_city_name <chr>,
#> # origin_state <chr>, dest_city_name <chr>,
#> # dest_state <chr>, taxi_out <dbl>, taxi_in <dbl>,
#> # carrier_delay <dbl>, weather_delay <dbl>,
#> # nas_delay <dbl>, security_delay <dbl>,
#> # late_aircraft_delay <dbl>
```
]

???

If you're familiar with the tidyverse, no much learning curve.

---

.left-column[
## Verbs
### - filter
### - select
]
.right-column[
Keep the index hanging around with the tsibble

```r
us_flights %>%
  select(flight, origin, dep_delay)
```

```
#> # A tsibble: 5,548,445 x 4 [!]
#> # Key: flight, origin [161,976]
#> flight origin dep_delay sched_dep_datetime
#> <chr> <chr> <dbl> <dttm>
#> 1 AA1 JFK 31 2017-01-01 08:00:00
#> 2 AA1 JFK -3 2017-01-02 08:00:00
#> 3 AA1 JFK -6 2017-01-03 08:00:00
#> 4 AA1 JFK -3 2017-01-04 08:00:00
#> 5 AA1 JFK -7 2017-01-05 08:00:00
#> 6 AA1 JFK -3 2017-01-06 08:00:00
#> # ... with 5.548e+06 more rows
```

OR *consciously* leave off the time context by using `.drop = TRUE` or `as_tibble()`.
]

---

.left-column[
## Verbs
### - filter
### - select
### - summarise
]
.right-column[
Aggregate over time

```r
us_flights %>%
  summarise(avg_delay = mean(dep_delay))
```

```
#> # A tsibble: 393,009 x 2 [!]
#> sched_dep_datetime avg_delay
#> <dttm> <dbl>
#> 1 2017-01-01 00:14:00 -5
#> 2 2017-01-01 00:15:00 -6.67
#> 3 2017-01-01 00:20:00 -3
#> 4 2017-01-01 00:21:00 17
#> 5 2017-01-01 00:30:00 -1
#> 6 2017-01-01 00:35:00 -4.5
#> # ... with 3.93e+05 more rows
```
Utilize the context and reduce typing, compared to:
```r
flights %>%
 group_by(sched_dep_datetime) %>%
 summarise(avg_delay = mean(dep_delay))
```

]

---

```r
us_flights %>%
  index_by(dep_date = as_date(sched_dep_datetime))
```

```
#> # A tsibble: 5,548,445 x 23 [!]
#> # Key: flight, origin [161,976]
#> # Groups: @ dep_date [365]
#> flight sched_dep_datetime sched_arr_datetime dep_delay
#> <chr> <dttm> <dttm> <dbl>
#> 1 AA1 2017-01-01 08:00:00 2017-01-01 11:42:00 31
#> 2 AA1 2017-01-02 08:00:00 2017-01-02 11:42:00 -3
#> 3 AA1 2017-01-03 08:00:00 2017-01-03 11:42:00 -6
#> 4 AA1 2017-01-04 08:00:00 2017-01-04 11:42:00 -3
#> 5 AA1 2017-01-05 08:00:00 2017-01-05 11:42:00 -7
#> 6 AA1 2017-01-06 08:00:00 2017-01-06 11:42:00 -3
#> # ... with 5.548e+06 more rows, and 19 more variables:
#> # arr_delay <dbl>, carrier <chr>, tailnum <chr>,
#> # origin <chr>, dest <chr>, air_time <dbl>,
#> # distance <dbl>, origin_city_name <chr>,
#> # origin_state <chr>, dest_city_name <chr>,
#> # dest_state <chr>, taxi_out <dbl>, taxi_in <dbl>,
#> # carrier_delay <dbl>, weather_delay <dbl>,
#> # nas_delay <dbl>, security_delay <dbl>,
#> # late_aircraft_delay <dbl>, dep_date <date>
```
]

---

```r
us_flights %>%
  index_by(dep_date = as_date(sched_dep_datetime)) %>%
  summarise(avg_delay = mean(dep_delay))
```

```
#> # A tsibble: 365 x 2 [1D]
#> dep_date avg_delay
#> <date> <dbl>
#> 1 2017-01-01 11.7
#> 2 2017-01-02 25.2
#> 3 2017-01-03 18.3
#> 4 2017-01-04 13.1
#> 5 2017-01-05 17.6
#> 6 2017-01-06 16.6
#> # ... with 359 more rows
```
* `year()` for yearly aggregation, `yearquarter()` for quarterly, `yearmonth()` for monthly, `yearweek()` for weekly
* other lubridate friends: `floor_date()`, `ceiling_date()`
]

---

### .bg-col[Each verb is self-explanatory and helps reason about data analysis.]

### .bg-col[Common tidyverse verbs help reduce cognitive load and make easy transition to time series analysis.]

### .bg-col[The pipe operator %>% chains a sequence of verbs to compose a sound pipeline.]

---

background-image: url(figure/carrier-mosaic-bg-1.svg)
background-size: 130%
background-position: -200px -50px

## .bg-col[Annual carrier on-time performance]

---

```r
delayed_carrier <- us_flights %>%
 mutate(delayed = dep_delay > 15) %>%
 group_by(carrier) %>%
 index_by(year = year(sched_dep_datetime)) %>%
 summarise(
 Ontime = sum(delayed == 0),
 Delayed = sum(delayed)
 ) %>%
 gather(delayed, n_flights, Ontime:Delayed) %>%
 print()
```

```
#> # A tsibble: 24 x 4 [?]
#> # Key: carrier, delayed [24]
#> carrier year delayed n_flights
#> <chr> <dbl> <chr> <int>
#> 1 AA 2017 Ontime 738556
#> 2 AS 2017 Ontime 160386
#> 3 B6 2017 Ontime 206185
#> 4 DL 2017 Ontime 780785
#> 5 EV 2017 Ontime 267154
#> 6 F9 2017 Ontime 81163
#> # ... with 18 more rows
```
]

---

```r
us_flights %>%
* mutate(delayed = dep_delay > 15)
```

```
#> # A tsibble: 5,548,445 x 23 [!]
#> # Key: flight, origin [161,976]
#> flight sched_dep_datetime sched_arr_datetime dep_delay
#> <chr> <dttm> <dttm> <dbl>
#> 1 AA1 2017-01-01 08:00:00 2017-01-01 11:42:00 31
#> 2 AA1 2017-01-02 08:00:00 2017-01-02 11:42:00 -3
#> 3 AA1 2017-01-03 08:00:00 2017-01-03 11:42:00 -6
#> 4 AA1 2017-01-04 08:00:00 2017-01-04 11:42:00 -3
#> 5 AA1 2017-01-05 08:00:00 2017-01-05 11:42:00 -7
#> 6 AA1 2017-01-06 08:00:00 2017-01-06 11:42:00 -3
#> # ... with 5.548e+06 more rows, and 19 more variables:
#> # arr_delay <dbl>, carrier <chr>, tailnum <chr>,
#> # origin <chr>, dest <chr>, air_time <dbl>,
#> # distance <dbl>, origin_city_name <chr>,
#> # origin_state <chr>, dest_city_name <chr>,
#> # dest_state <chr>, taxi_out <dbl>, taxi_in <dbl>,
#> # carrier_delay <dbl>, weather_delay <dbl>,
#> # nas_delay <dbl>, security_delay <dbl>,
#> # late_aircraft_delay <dbl>, delayed <lgl>
```

---

.block[
.flowchart[
* `mutate()` create dummy variable
* `index_by() + summarise()` aggregate to annual data
]
]

```r
us_flights %>%
  mutate(delayed = dep_delay > 15) %>%
* group_by(carrier) %>%
* index_by(year = year(sched_dep_datetime)) %>%
* summarise(
*   Ontime = sum(delayed == 0),
*   Delayed = sum(delayed)
* )
```

```
#> # A tsibble: 12 x 4 [?]
#> # Key: carrier [12]
#> carrier year Ontime Delayed
#> <chr> <dbl> <int> <int>
#> 1 AA 2017 738556 136344
#> 2 AS 2017 160386 22670
#> 3 B6 2017 206185 72034
#> 4 DL 2017 780785 128534
#> 5 EV 2017 267154 61420
#> 6 F9 2017 81163 20365
#> 7 HA 2017 73498 6245
#> 8 NK 2017 122141 28028
#> 9 OO 2017 582553 111461
#> 10 UA 2017 480623 93485
#> 11 VX 2017 52575 17107
#> 12 WN 2017 1035170 269963
```

---

.block[
.flowchart[
* `mutate()` create dummy variable
* `index_by() + summarise()` aggregate to annual data
* `gather()` melt to long form
]
]

```r
us_flights %>%
  mutate(delayed = dep_delay > 15) %>%
  group_by(carrier) %>%
  index_by(year = year(sched_dep_datetime)) %>%
  summarise(
    Ontime = sum(delayed == 0),
    Delayed = sum(delayed)
  ) %>%
* gather(delayed, n_flights, Ontime:Delayed)
```

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
]
.right-column[
<img src="figure/carrier-mosaic-1.svg" style="display: block; margin: auto;" />

> Delta operates most efficiently among those big carriers.
]

---

background-image: url(figure/nyc-monthly-plot-bg-1.svg)
background-size: 130%
background-position: -200px -50px

## .bg-col[Daily delay percentages in New York]

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
### - nyc
]
.right-column[

```r
nyc_flights <- us_flights %>%
 filter(origin %in% c("JFK", "LGA", "EWR"))
```

```r
nyc_delay <- nyc_flights %>%
 mutate(delayed = dep_delay > 15) %>%
 group_by(origin) %>%
 index_by(sched_dep_date = as_date(sched_dep_datetime)) %>%
 summarise(
 n_flights = n(),
 n_delayed = sum(delayed)
 ) %>%
 mutate(pct_delay = n_delayed / n_flights) %>%
 print()
```

```
#> # A tsibble: 1,095 x 5 [1D]
#> # Key: origin [3]
#> origin sched_dep_date n_flights n_delayed pct_delay
#> <chr> <date> <int> <int> <dbl>
#> 1 EWR 2017-01-01 294 63 0.214
#> 2 EWR 2017-01-02 327 118 0.361
#> 3 EWR 2017-01-03 322 153 0.475
#> 4 EWR 2017-01-04 315 95 0.302
#> 5 EWR 2017-01-05 317 91 0.287
#> 6 EWR 2017-01-06 294 97 0.330
#> # ... with 1,089 more rows
```
]

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
### - nyc
]
.right-column[
<img src="figure/nyc-delay-plot-1.svg" style="display: block; margin: auto;" />
]

---

## A suite of window functions

---

## A suite of window functions

* `tile()`/`tile2()`/`ptile()`: tiling window without overlapping observations
]

---

## A suite of window functions

* `tile()`/`tile2()`/`ptile()`: tiling window without overlapping observations

* `stretch()`/`stretch2()`/`pstretch()`: fixing an initial window and expanding to include more observations
]

<hr>

`purrr`-like interface: `~ mean(.x)`. Functional programming is always fun!

Type-stable: `slide()`/`tile()`/`stretch()` (a list) other variants: `*_dbl()`, `*_int()`, `*_lgl()`, `*_chr()`

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
### - nyc
]
.right-column[
## Fixed window size

```r
nyc_weekly <- nyc_delay %>%
 group_by(origin) %>%
* mutate(ma_delay = slide_dbl(
* pct_delay, mean, .size = 7, .align = "center"
* ))
nyc_weekly %>% select(origin, ma_delay)
```

```
#> # A tsibble: 1,095 x 3 [1D]
#> # Key: origin [3]
#> # Groups: origin [3]
#> origin ma_delay sched_dep_date
#> <chr> <dbl> <date>
#> 1 EWR NA 2017-01-01
#> 2 EWR NA 2017-01-02
#> 3 EWR NA 2017-01-03
#> 4 EWR 0.346 2017-01-04
#> 5 EWR 0.403 2017-01-05
#> 6 EWR 0.412 2017-01-06
#> # ... with 1,089 more rows
```
]

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
### - nyc
]
.right-column[
<img src="figure/nyc-weekly-plot-1.svg" style="display: block; margin: auto;" />

> Increase the window size to smooth out short-term fluctuations.
]

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
### - nyc
]
.right-column[
## Flexible calendar period

```r
nyc_lst <- nyc_delay %>%
 mutate(yrmth = yearmonth(sched_dep_date)) %>%
 group_by(origin, yrmth) %>%
 nest() %>%
 print()
```

```
#> # A tibble: 36 x 3
#> origin yrmth data
#> <chr> <mth> <list>
#> 1 EWR 2017 Jan <tsibble [31 × 4]>
#> 2 EWR 2017 Feb <tsibble [28 × 4]>
#> 3 EWR 2017 Mar <tsibble [31 × 4]>
#> 4 EWR 2017 Apr <tsibble [30 × 4]>
#> 5 EWR 2017 May <tsibble [31 × 4]>
#> 6 EWR 2017 Jun <tsibble [30 × 4]>
#> # ... with 30 more rows
```
]

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
### - nyc
]
.right-column[
## Flexible calendar period

```r
nyc_monthly <- nyc_lst %>%
 group_by(origin) %>%
* mutate(monthly_ma = slide_dbl(data,
* ~ mean(.$pct_delay), .size = 2, .bind = TRUE
* )) %>%
 unnest(key = id(origin)) %>%
 print()
```

```
#> # A tsibble: 1,095 x 7 [1D]
#> # Key: origin [3]
#> origin yrmth monthly_ma sched_dep_date n_flights
#> <chr> <mth> <dbl> <date> <int>
#> 1 EWR 2017 Jan NA 2017-01-01 294
#> 2 EWR 2017 Jan NA 2017-01-02 327
#> 3 EWR 2017 Jan NA 2017-01-03 322
#> 4 EWR 2017 Jan NA 2017-01-04 315
#> 5 EWR 2017 Jan NA 2017-01-05 317
#> 6 EWR 2017 Jan NA 2017-01-06 294
#> # ... with 1,089 more rows, and 2 more variables:
#> # n_delayed <int>, pct_delay <dbl>
```
]

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
### - nyc
]
.right-column[
<img src="figure/nyc-monthly-plot-1.svg" style="display: block; margin: auto;" />

> 2-month moving averages highlight a stable long-term trend.
]

---

background-image: url(figure/draw-qtl-bg-1.svg)
background-size: 130%
background-position: -200px -50px

## .bg-col[Hourly upper-tail delay behaviours]

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
### - nyc
### - upper tail
]
.right-column[

```r
hr_qtl <- us_flights %>%
 index_by(dep_datehour = floor_date(sched_dep_datetime, "hour")) %>%
 summarise(
 qtl50 = quantile(dep_delay, 0.5),
 qtl80 = quantile(dep_delay, 0.8),
 qtl95 = quantile(dep_delay, 0.95)
 ) %>%
 mutate(
 hour = hour(dep_datehour),
 wday = wday(dep_datehour, label = TRUE, week_start = 1),
 date = as_date(dep_datehour)
 ) %>%
 gather(key = qtl, value = dep_delay, qtl50:qtl95) %>%
 print()
```

```
#> # A tsibble: 24,012 x 6 [1h]
#> # Key: qtl [3]
#> dep_datehour hour wday date qtl dep_delay
#> <dttm> <int> <ord> <date> <chr> <dbl>
#> 1 2017-01-01 00:00:00 0 Sun 2017-01-01 qtl50 -3.5
#> 2 2017-01-01 01:00:00 1 Sun 2017-01-01 qtl50 -2
#> 3 2017-01-01 02:00:00 2 Sun 2017-01-01 qtl50 -7
#> 4 2017-01-01 05:00:00 5 Sun 2017-01-01 qtl50 -2
#> 5 2017-01-01 06:00:00 6 Sun 2017-01-01 qtl50 -3
#> 6 2017-01-01 07:00:00 7 Sun 2017-01-01 qtl50 -2
#> # ... with 2.401e+04 more rows
```
]

---

.left-column[
.center[<img src="img/tsibble.png" height=110px>]
### - carrier
### - nyc
### - upper tail
]
.right-column[
<img src="figure/draw-qtl-1.svg" style="display: block; margin: auto;" />

> Travel smart: avoid flying around 6pm during the day.
]

---

### .bg-col[Break up a big problem to into manageable blocks]

### .bg-col[Generate human-readable and error-prone analysis workflow]

---

## Look ahead

.center[
<img src="img/tsibble.png" height=230px>
<img src="img/fable.png" height=230px>
### [tidyverts.org](tidyverts.org)
]

---

### Joint work with [Di Cook](http://dicook.org) & [Rob J Hyndman](http://robjhyndman.com)

### Slides created via xaringan ⚔️ <http://slides.earo.me/bigapple>

### More about tsibble <http://pkg.earo.me/tsibble>

### Open source <https://github.com/earowang/bigapple>

### This work is under licensed [ BY-NC 4.0](https://creativecommons.org/licenses/by-nc/4.0/).
